MIWE electro

Any more for any more?

The professional deck oven with electric heating

Makes a good impression in bakehouses and shops: the electrically heated deck oven MIWE electro. With four or six decks in two heights (17, 22 cm), two widths (60, 120 cm) and two depths (160, 200 cm), it can reach baking areas of up to 14.4 m². In doing so, it also guarantees a perfectly even baking result for the entire range, from sensitive confectioneries to heavy breads.

The professional deck oven with electric heating

Makes a good impression in bakehouses and shops: the electrically heated deck oven MIWE electro. With four or six decks in two heights (17, 22 cm), two widths (60, 120 cm) and two depths (160, 200 cm), it can reach baking areas of up to 14.4 m². In doing so, it also guarantees a perfectly even baking result for the entire range, from sensitive confectioneries to heavy breads.

Variants of the MIWE electro

Experience the MIWE electro from all perspectives in this 3D model.

Would you like to see how the MIWE electro would fit into your bakery?
Simply activate the augmented reality feature (AR) with your smartphone or tablet!

What makes the MIWE electro so unique

A master baker through and through

As befits a real professional, every deck in the MIWE electro has its own steam-tight encapsulated steam unit and an individual control system for top and bottom heat. This allows a wide range of products to be baked to perfection simultaneously. As the MIWE electro heats up quickly, you do not have to wait for a long time before baking. Rapid batch after batch is easy to do with it. In short: Everything good is combined here.

Clear target group

The MIWE electro is the ideal choice wherever a  is too small and a is too big for the planned tasks, or where the infrastructure requires electric heating. As its decks are lined with stone slabs, you can call bread baked in it "stone-baked bread".

Economical

As every deck is isolated individually, and can also be activated and deactivated individually, MIWE electro is intrinsically extremely energy efficient. The individually configurable heating levels help with this, but primarily ensure that every product receives exactly the quantity of energy it needs for a perfect baking result.

Making a lot of things easier: draw-plate oven decks

On request, we also offer the MIWE electro with a self-supporting, stable draw-plate oven deck or alternatively a front part table. Because we want to make baking easier.

Equipped for automation

Wherever process rationalisation and automation are required, the MIWE athlet automatic loading system is the ideal addition to the MIWE electro.

How the MIWE electro helps you save energy

Saving energy is more important than ever. MIWE has the answers.

Standarddatei

Energy saving and flexibility thanks to oven decks that can be switched on and off individually

Standarddatei

Precise energy use through individually adjustable heating power levels

Standarddatei

Strict reduction of heat loss through multi-therm insulation and heat-reflecting coating

Standarddatei

Efficient and forward-looking baking with MIWE Autostart and MIWE Eco mode

Everything you need to know

Accessories

  • Automation technology MIWE sherpa and MIWE athlet and with peripheral equipment
  • Steam hood
  • Steam condenser
  • Extendable storage bars
  • Front part table

Options

  • Draw-plate oven deck
  • Touch Control MIWE TC

Technical information

Size 60 x 160

Number of baking chambers

4

5

6

Model

EL 4.0616

Baking area in m²

3.84

Baking chamber in cm (W x D x H)

60 x 160 x 17 or 60 x 160 x 22

Exterior dimensions in cm (W x D x H)

100 x 242 x 233 or 100 x 242 x 253

    Steam hood height in cm

    24

    Loading height in cm at bottom/top

    78/162

    High power kw

    28.6

    Steam generator kw

    2.0

    Model

    EL 5.0616

    Baking area in m²

    4.8

    Baking chamber in cm (W x D x H)

    60 x 160 x 17 or 60 x 160 x 22

      Exterior dimensions in cm (W x D x H)

      100 x 242 x 233 or 100 x 242 x 258

        Steam hood height in cm

        24

        Loading height in cm at bottom/top

        50/162

        High power kw

        35.7

        Steam generator kw

        2.0

        Model

        EL 6.0616

        Baking area in m²

        5.76

        Baking chamber in cm (W x D x H)

        60 x 160 x 17 or 60 x 160 x 22

          Exterior dimensions in cm (W x D x H)

          100 x 242 x 233 or 100 x 242 x 263

            Steam hood height in cm

            24

            Loading height in cm at bottom/top

            32/172

            High power kw

            42.9

            Steam generator kw

            2.0

            Size 120x160

            Number of baking chambers

            4

            5

            6

            Model

            EL 4.1216

            Baking area in m²

            7.7

            Baking chamber in cm (W x D x H)

            120 x 160 x 17 or 60 x 160 x 22

              Exterior dimensions in cm (W x D x H)

              160 x 242 x 233 or 160 x 242 x 253

                Steam hood height in cm

                24

                Loading height in cm at bottom/top

                78/162

                High power kw

                40.6

                Steam generator kw

                3.0

                Model

                EL 5.1216

                Baking area in m²

                9.6

                Baking chamber in cm (W x D x H)

                120 x 160 x 17 or 60 x 160 x 22

                  Exterior dimensions in cm (W x D x H)

                  160 x 242 x 233 or 160 x 242 x 258

                    Steam hood height in cm

                    24

                    Loading height in cm at bottom/top

                    50/162

                    High power kw

                    50.8

                    Steam generator kw

                    3.0

                    Model

                    EL 6.1216

                    Baking area in m²

                    11.5

                    Baking chamber in cm (W x D x H)

                    120 x 160 x 17 or 60 x 160 x 22

                      Exterior dimensions in cm (W x D x H)

                      160 x 242 x 233 or 160 x 242 x 263

                        Steam hood height in cm

                        24

                        Loading height in cm at bottom/top

                        32/172

                        High power kw

                        61.0

                        Steam generator kw

                        3.0

                        Size 120 x 200

                        Number of baking chambers

                        4

                        5

                        6

                        Model

                        EL 4.1220

                        Baking area in m²

                        9.6

                        Baking chamber in cm (W x D x H)

                        120 x 200 x 17 or 60 x 160 x 22

                          Exterior dimensions in cm (W x D x H)

                          160 x 282 x 233 or 160 x 282 x 253

                            Steam hood height in cm

                            24

                            Loading height in cm at bottom/top

                            78/162

                            High power kw

                            48.2

                            Steam generator kw

                            3.0

                            Model

                            EL 5.1220

                            Baking area in m²

                            12.0

                            Baking chamber in cm (W x D x H)

                            120 x 200 x 17 or 60 x 160 x 22

                              Exterior dimensions in cm (W x D x H)

                              160 x 282 x 233 or 160 x 282 x 258

                                Steam hood height in cm

                                24

                                Loading height in cm at bottom/top

                                50/162

                                High power kw

                                60.2

                                Steam generator kw

                                3.0

                                Model

                                EL 6.1220

                                Baking area in m²

                                14.4

                                Baking chamber in cm (W x D x H)

                                120 x 200 x 17 or 60 x 160 x 22

                                  Exterior dimensions in cm (W x D x H)

                                  160 x 282 x 233 or 160 x 282 x 263

                                    Steam hood height in cm

                                    24

                                    Loading height in cm at bottom/top

                                    32/172

                                    High power kw

                                    72.3

                                    Steam generator kw

                                    3.0

                                    Documents

                                    Product information
